- 产品名称：HDMI电缆
- 浏览：
- 添加时间：2015-06-06 17:32:02
- 推荐度：
产品介绍：
|
产品型号
|
HDMI(30AWG)
|
HDMI(28AWG)
|
HDMI(26AWG)
|
HDMI(24AWG)
|
|
产品编号
|
|
|
|
|
|
芯数
|
5P*30AWG
|
5P*28AWG
|
5P*26AWG
|
5P*24AWG
|
|
+4C*30AWG
|
+4C*28AWG
|
+4C*26AWG
|
+4C*24AWG
|
|
|
导体规格(mm)
|
10 / 7*38AWG
|
10 / 7*36AWG
|
10 / 7*34AWG
|
10 / 7*32AWG
|
|
4 / 7*38AWG
|
4 / 7*36AWG
|
4 / 7*34AWG
|
4 / 7*32AWG
|
|
|
导体材料
|
镀锡铜
|
镀锡铜
|
镀锡铜
|
镀锡铜
|
|
绝缘线径(mm)
|
10 / 0.78
|
10 / 0.98
|
10 / 1.1
|
10 / 1.2
|
|
4 / 0.62
|
4 / 0.70
|
4 / 0.90
|
4 / 1.0
|
|
|
绝缘材料
|
5P 泡皮PE
|
5P 泡皮PE
|
5P 泡皮PE
|
5P 泡皮PE
|
|
4C 实芯PE
|
4C 实芯PE
|
4C 实芯PE
|
4C 实芯PE
|
|
|
屏蔽材料
|
铝箔/地线/
镀锡铜线编织
|
铝箔/地线/
镀锡铜线编织
|
铝箔/地线/
镀锡铜线编织
|
铝箔/地线/
镀锡铜线编织
|
|
屏蔽覆盖率
|
100%
|
100%
|
100%
|
100%
|
|
外被材料
|
PVC
|
PVC
|
PVC
|
PVC
|
|
外被线径(mm)
|
6.1
|
7.4
|
8.35
|
9.4
|
|
导体电阻(Ω/100m)
|
<37.63
|
<23.33
|
<14.7
|
<9.14
|
|
额定电压
|
30V
|
30V
|
30V
|
30V
|
|
额定温度
|
80℃
|
80℃
|
80℃
|
80℃
|
|
阻抗 (Ω)
|
100 ±10
|
100 ±10
|
100 ±10
|
100 ±10
|
|
延迟速率
|
线对:
|
线对:
|
线对:
|
线对:
|
|
≤112ps/m Between pair:
|
≤112ps/m Between pair:
|
≤112ps/m Between pair:
|
≤112ps/m Between pair:
|
|
|
≤5.5ns/m
|
≤5.5ns/m
|
≤5.5ns/m
|
≤5.5ns/m
|
|
|
衰减
|
300KHz-825MHz
<5
|
300KHz-825MHz
<5
|
300KHz-825MHz
<5
|
300KHz-825MHz
<5
|
|
825MHz-2.475GHz
<12
|
825MHz-2.475GHz
<12
|
825MHz-2.475GHz
<12
|
825MHz-2.475GHz
<12
|
|
|
2.475GHz-4.125GHz
<20
|
2.475GHz-4.125GHz
<20
|
2.475GHz-4.125GHz
<20
|
2.475GHz-4.125GHz
<20
|
|
|
4.125GHz-5.1GHz
<25
|
4.125GHz-5.1GHz
<25
|
4.125GHz-5.1GHz
<25
|
4.125GHz-5.1GHz
<25
|
|
|
回波
|
>20dB
|
>20dB
|
>20dB
|
>20dB
|
|
包装长度 (m)
|
1.0 / 1.8 / 3.0
|
1.0 / 1.8 / 3.0
|
1.0 / 1.8 / 3.0
|
1.0 / 1.8 / 3.0
|
